• Connector Shape : Rectangular

• Mixed & Hybrid Connector : No

• Connector & Housing Type : Housing for Female Terminals

• Connector System : Wire-to-Wire

• Sealable : Yes

• Primary Locking Feature : Integrated in Housing

• Connector & Contact Terminates To : Wire & Cable

• Number of Positions : 6

• Number of Rows : 2

• Operating Voltage (VDC): 14

• Cable Exit Angle : 180°

• Primary Product Color : Blue

• Connector & Keying Code : E

• Contact Type : Receptacle

• Contact Size : 1.5K

• Mating Tab Width : 1.5 mm [ .059 in ]

• Mating Alignment : With

• Mating Alignment Type : Keyed

• Terminal Position Assurance : Yes

• Strain Relief : Without

• Connector Mounting Type : Cable Mount (Free-Hanging)

• Housing Material : PA

• Centerline (Pitch) : 4 mm [ .157 in ]

• Connector Height : 27.3 mm [ 1.075 in ]

• Product Length : 25.5 mm [ 1.004 in ]

• Product Width : 36.4 mm [ 1.433 in ]

• Row-to-Row Spacing : 2.54 mm [ .1 in ]

• Circuit Application : Power

• Packaging Method : Box & Carton

• Packaging Quantity : 450
