• Connector & Contact Terminates To : Wire & Cable

• Connector & Housing Type : Receptacle

• Connector Product Type : Housing

• Sealable : No

• Connector System : Wire-to-Wire

• Circular Connector Shell Type : All Plastic

• Number of Power Positions : 0

• Reverse Numbering : Without

• Number of Positions : 14

• Number of Signal Positions : 14

• Operating Voltage (VDC): 600

• Operating Voltage (VAC): 600

• Contact Protection : With

• Reverse Gender : Yes

• Contact Type : Socket

• Connector Mounting Type : Panel Mount

• Mating Alignment Type : Keyed

• Panel Mount Feature Type : Flange with Mounting Holes

• Mating Alignment : With

• Thread Size : 15/16-20 UNEF – 2A

• Panel Mount Feature : With

• Mating Retention : With

• Mating Retention Type : Threaded Coupling

• Body Orientation : Straight

• Housing Material : Thermoplastic

• Housing Color : Black

• Circular Connector Shell Size : 17

• Operating Temperature Range : -55 – 105 °C [ -67 – 221 °F ]

• Fluid Resistance : None

• Shielded : No

• Circuit Application : Power & Signal

• UL Flammability Rating : UL 94V-0

• CSA Rating : Certified
