Please review product documents or contact us for the latest agency approval information.

Please Note: Use the Product Drawing for all design activity.

• Number of Circuits : 1

• Number of Poles : 2

• Gauge Type : A5

• Number of Levels : 1

• Block Function : Feed-Through

• Number of Positions : 2

• Product Weight : 12.8 g [ .451 oz ]

• Primary Product Color : Blue

• Product Height (mm): 44.5

• Product Length (mm): 40.5

• Product Width : 8 mm [ .314 in ]

• Main Circuit Capacity - 1 Flexible Conductor per Spring Clamp (mm²): .5 – 6

• Main Circuit Capacity - 1 Rigid Stranded Conductor per Screw Clamp (mm²): .5 – 10

• Wire Stripping Length : 12 mm [ .472 in ]

• Product Depth (mm): 40.5

• Product Spacing : 8 mm [ .314 in ]

• Wire Size (AWG): 8

• Wire Size (mm²): 6

• Tightening Torque (in-lbs): 7.1

• Tightening Torque (Nm): .8

• DIN Rail Mounting Type : TH35-15, TH35-7.5, G32

• Connector Mounting Type : DIN Rail

• Short-Time Withstanding Current Rating @ 1s (A): 720

• Voltage Rating (CSA) (V): 600

• Voltage Rating (IEC) (V): 1000

• Dielectric Withstanding Voltage (Max) (V): 2000

• Current Rating (CSA) (A): 50

• Current Rating (UL) (A): 50

• Current Rating (IEC) (A): 41

• Impulse Withstanding Voltage Rating (IEC) (V): 8000

• Operating Voltage Rating (UL & CSA) (Max) - Main Circuit (V): 600

• Operating Voltage (VAC): 1000

• Installation Temperature Range : -5 – 40 °C [ 23 – 104 °F ]

• Operating Temperature Range : -55 – 110 °C [ -67 – 230 °F ]

• UL Flammability Rating : UL 94V-0

• IP Rating : IP20

• Housing Material : Polyamide 6.6

• Modular Terminal Block Product Type : Screw Clamp Terminal Block

• Termination Method to Wire & Cable : Screw Terminal

• Circuit Application : Signal
