Please review product documents or contact us for the latest agency approval information.

Please Note: Use the Product Drawing for all design activity.

• Illuminated : With

• Switch Connection Type : Printed Circuit Board

• Leg Style : Kinked

• Actuator Style : Round Actuator

• Ganged : With

• ESD Grounding Terminal : Without

• Switch Feedback Type : Tactile

• Operating Function : NO

• Support Bracket : Without

• Configuration (Pole-Throw) : Single Pole - Single Throw

• Number of Actuators : Single

• Actuator Force : 160 g [ 5.64 oz ]

• Cover Material : PET Film

• Actuator Material : Nylon

• Case Color : Black

• Actuator Profile : Extended

• Case Material : Nylon

• Product Orientation : Vertical

• Actuator Color : Black

• Actuator Length : 9.4 mm [ .37 in ]

• Product Height (in): .512

• Button Width : 3.5 mm [ .138 in ]

• Packaging Method : Loose Piece

• Contact Current Rating (mA): 50

• Contact Base Material : Copper Alloy

• Switch Contact Plating Material : Silver

• Low Profile : With

• Process Sealed : No

• Operating Voltage (VDC): 24

• Termination Method to PCB : Through Hole - Solder

• Operating Temperature Range (°C): -40 – 105
