Please review product documents or contact us for the latest agency approval information.

Please Note: Use the Product Drawing for all design activity.

• Contact Mating Area Plating Material Thickness (µin): 30

• PCB Contact Termination Area Plating Material : Tin, Tin over Nickel

• Contact Base Material : Phosphor Bronze

• Contact Mating Area Plating Material : Gold

• Contact Options : Installed

• Connector & Housing Type : Receptacle

• Connector System : Cable-to-Board

• Connector & Contact Terminates To : Printed Circuit Board

• Shell Material Configuration : Full Metal Shell

• Number of Positions : 50

• Number of Rows : 4

• PCB Mount Orientation : Right Angle

• Centerline (Pitch) : 1.27 mm [ .05 in ]

• Shell Material : Zinc Die Cast

• Housing Material : PBT

• Row-to-Row Spacing : 2.54 mm [ .1 in ]

• Connector Profile : Standard

• Primary Product Color : Black

• Shell Plating Material : Nickel over Copper

• Shield Material : Zinc Die Cast

• Shield Plating Material : Nickel over Copper

• PCB Mount Retention : With

• PCB Mount Retention Type : Mounting Hole

• Mating Retention : With

• Mating Retention Type : Screwlocks

• Connector Mounting Type : Board Mount

• PCB Mount Alignment : Without

• Mating Alignment : Without

• Mounting Hole Diameter (mm): 2.7

• Circuit Application : Signal

• Shielded : Yes

• Operating Temperature Range : -55 – 105 °C [ -67 – 221 °F ]

• EU RoHS Compliance : Compliant

• EU ELV Compliance : Compliant

• Termination Post & Tail Length : 3.8 mm [ .15 in ]

• Termination Method to PCB : Through Hole - Solder

• Rectangular Termination Post & Tail Thickness : .4 mm [ .015 in ]

• Rectangular Termination Post & Tail Width : .45 mm [ .017 in ]

• UL Flammability Rating : UL 94V-0
