Please review product documents or contact us for the latest agency approval information.

• Product Line : Poke-In

• Connector System : Wire-to-Board

• Connector & Contact Terminates To : Printed Circuit Board, Wire & Cable

• Compatible Insulation Diameter Range : 2.1 mm [ .083 in ]

• Connector Height : 3.9 mm [ .154 in ]

• Wire Size (AWG): 18 – 22

• Contact Mating Area Plating Material Thickness : 3 µm [ 118 µin ]

• Contact Mating Area Plating Material Finish : Matte

• Contact Fabrication : Stamped & Formed

• PCB Contact Termination Area Plating Material Finish : Matte

• PCB Contact Termination Area Plating Material : Tin

• Contact Mating Area Plating Material : Tin

• Contact Layout : Inline

• PCB Contact Termination Area Plating Material Thickness : 3 µm [ 118.11 µin ]

• Contact Current Rating (Max) (A): 4

• Packaging Method : SMT Pocket Tape

• PCB Mount Retention : Without

• Connector Mounting Type : Board Mount

• Header Mating Direction : Horizontal

• Primary Product Color : White

• Compatible With Approved Standards Products : UL E28476, UL 1977, CSA/C22.2 No. 182.3-M1987

• UL Flammability Rating : UL 94V-0

• Compatible With Agency/Standards Products : UL, CSA

• Operating Voltage (VDC): 250

• Operating Voltage (VAC): 250

• Number of Positions : 2

• Termination Method to PCB : Through Hole - Solder

• Centerline (Pitch) : 4 mm [ .157 in ]

• Operating Temperature Range : -40 – 105 °C [ -40 – 221 °F ]

• Circuit Application : Power & Signal
