Please review product documents or contact us for the latest agency approval information.

• Solder Process : Wave Solder

• Current Type : DC

• Coil Magnetic System : Monostable

• Coil Special Features : UL Coil Insulation Class F

• Contact Number of Poles : 1

• Contact Arrangement : 1 Form A SPST-NO

• Insulation Initial Resistance (MΩ): 1000

• Coil Resistance (Ω): 432 – 528

• Contact Switching Load (Min) : 1000mA @ 5VDC

• Contact Switching Voltage (Max) (VAC): 277

• Coil Current (A): .05

• Insulation Initial Dielectric Between Open Contacts (Vrms): 2000

• Contact Limiting Breaking Current (A): 16

• Contact Limiting Continuous Current (A): 32

• Contact Limiting Making Current (A): 16

• Contact Current Rating (A): 32

• Coil Voltage Rating (VDC): 24

• Contact Voltage Rating (VAC): 277

• Coil Power Rating DC (W): 1.2

• Insulation Initial Dielectric Between Contacts & Coil (Vrms): 4000

• Primary Product Color : Black

• Product Weight : 16 g [ .564 oz ]

• Enclosure Type : Flux Resistant Automatic Soldering

• Environmental Category of Protection : RTII

• Operating Temperature Range : -40 – 105 °C [ -40 – 221 °F ]

• Environmental Ambient Temperature (Max) : 105 °C [ 221 °F ]

• Environmental Ambient Temperature Class (°C): 95 – 105

• Contact Current Class (A): 16 – 32

• Coil Power Rating Class (W): 1.1 – 1.3

• Length Class (Mechanical) (mm): 21.1–21.9

• Width Class (Mechanical) (mm): 15.6 – 16.4

• EU RoHS Compliance : Compliant

• EU ELV Compliance : Compliant

• Packaging Method : Tray/Box

• Product Height : 20.6 mm [ .811 in ]

• Product Length : 21.5 mm [ .846 in ]

• Product Width : 16 mm [ .629 in ]

• Insulation Creepage Between Contact & Coil : 5 mm [ .197 in ]

• Insulation Clearance Between Contact & Coil : 3 mm [ .118 in ]

• Contact Material : AgSnO2

• Relay & Contactor Type : General Purpose Power Relay

• Main Termination & Connection Type : Solder Pins

• Coil Termination & Connection Type : Solder Pins
