Please review product documents or contact us for the latest agency approval information.

• Connector Shape : Rectangular

• Connector & Housing Type : Housing for Female Terminals

• Primary Locking Feature : On the Terminal

• Sealable : No

• Connector System : Wire-to-Device, Wire-to-Board

• Mixed & Hybrid Connector : Yes

• Number of Positions : 18

• Number of Rows : 2

• Operating Voltage (VDC): 12

• Nominal Voltage Architecture (V): 12

• Primary Product Color : White

• Cable Exit Angle : 180°

• Mating Tab Width : 1.5 mm [ .059 in ]

• Contact Size : 1.5mm, 2.8mm

• Contact Type : Receptacle

• Connector Mounting Type : Cable Mount (Free-Hanging)

• Mating Alignment Type : Keyed

• Terminal Position Assurance : Yes

• Mating Alignment : With

• Strain Relief : Without

• Housing Material : PBT

• Centerline (Pitch) : 3.5 mm [ .138 in ]

• Product Width : 26 mm [ 1.024 in ]

• Connector Height : 19.6 mm [ .772 in ]

• Operating Temperature Range : -40 – 80 °C [ -40 – 176 °F ]

• Operating Temperature (Max) (°C): 70, 75, 80

• Operating Temperature (Max) (°F): 158, 167, 176

• Circuit Application : Signal
