Please review product documents or contact us for the latest agency approval information.

Please Note: Use the Product Drawing for all design activity.

• Connector Seal Code : T Seal

• Blank Cavity Position : 0

• Number of Positions : 31

• Connector Shape : Circular

• Mixed & Hybrid Connector : No

• Connector & Housing Type : Receptacle

• Connector System : Wire-to-Panel

• Sealable : Yes

• Primary Locking Feature : Contact Retainer

• Connector & Contact Terminates To : Wire & Cable

• Contact Type : Pin

• Contact Size : Size 16

• Mating Pin Diameter : 1.6 mm [ .063 in ]

• Contact Current Rating (Max) (A): 13

• Cable Exit Angle : 180°

• Primary Product Color : Black

• Serviceable : Yes

• Connector Position Assurance Capable : No

• EU RoHS Compliance : Compliant

• EU ELV Compliance : Compliant

• Mating Alignment : With

• Mating Alignment Type : Guide Post

• Terminal Position Assurance : No

• Strain Relief : Without

• Connector Mounting Type : Panel Mount

• Packaging Method : Tray

• Packaging Quantity : 30

• Connector Height : 41.5 mm [ 1.63 in ]

• Product Length : 50.8 mm [ 2 in ]

• Product Width : 47.6 mm [ 1.87 in ]

• Compatible Insulation Diameter Range : 1.4 – 3.8 mm [ .055 – .15 in ]

• UL Flammability Rating : UL 94V-0

• IP Rating : IP67

• Housing Material : PA 66 GF

• Operating Voltage (VDC): 250

• Operating Voltage (VAC): 250

• Operating Temperature (Max) : 125 °C [ 257 °F ]

• Operating Temperature Range : -55 – 125 °C [ -67 – 257 °F ]
