Sliver for SFF-TA-1002, Cable Plug Assembly, Vertical, Cable-to-Board, 168 Position, Surface Mount, Internal I/O Connectors
2384218-1
Sliver for SFF-TA-1002, Cable Plug Assembly, Vertical, Cable-to-Board, 168 Position, Surface Mount, Internal I/O Connectors
- TE Internal #: 2384218-1
- TE Internal Description: SLIVER 2.0 4C+ vertical receptacle
-
Internal I/O Connector Type : Sliver for SFF-TA-1002
-
Connector Mates With : Cable Plug Assembly
-
PCB Mount Orientation : Vertical
-
Connector System : Cable-to-Board
-
Industry Standard : Gen-Z
Documents
Product Drawings
- RECEPTACLE ASSEMBLY, VERTICAL, FOR SLIVER 2.0 168 POSITION ENG_CD_2384218_A1.pdf English
CAD Files
-
Download ECAD Model File
Download the free Library Loader to convert this file to your ECAD Tool. Learn more about the ECAD Model.
- 3D PDF 3D_CVM_CVM_2384218-1_1.pdf 3D
- Customer View Model ENG_CVM_CVM_2384218-1_1.2d_dxf.zip English
- ENG_CVM_CVM_2384218-1_1.3d_igs.zip English
- ENG_CVM_CVM_2384218-1_1.3d_stp.zip English
Product Specifications
- Product Specification ENG_SS_108-130021_A3.pdf English
