• Connector Shape : Rectangular

• Mixed & Hybrid Connector : No

• Connector & Housing Type : Housing for Female Terminals

• Connector System : Wire-to-Wire

• Sealable : Yes

• Primary Locking Feature : On the Terminal

• Connector & Contact Terminates To : Wire & Cable

• Housing Material : PA

• Centerline (Pitch) : 5 mm [ .196 in ]

• Cable Exit Angle : 180°

• Primary Product Color : Blue

• Connector & Keying Code : Neutral

• Operating Voltage (VDC): 24

• Nominal Voltage Architecture (V): 24

• Serviceable : No

• Connector Position Assurance Capable : No

• EU RoHS Compliance : Compliant

• EU ELV Compliance : Compliant

• Contact Type : Receptacle

• Contact Size : 2.8mm

• Contact Current Rating (Max) (A): 20

• Mating Alignment : With

• Mating Alignment Type : Polarizing Slot

• Terminal Position Assurance : Yes

• Strain Relief : Without

• Connector Mounting Type : Cable Mount (Free-Hanging)

• Packaging Method : Bag

• Connector Height : 37.5 mm [ 1.476 in ]

• Product Length : 23.5 mm [ .925 in ]

• Product Width : 24.4 mm [ .961 in ]

• Number of Positions : 2

• Number of Rows : 1

• Operating Temperature (Max) (°C): 125, 80, 105, 100, 90, 85, 75, 70, 110, 120

• Operating Temperature (Max) (°F): 248, 221, 158, 167, 230, 176, 194, 185, 212, 257

• Operating Temperature Range : -30 – 125 °C [ -22 – 257 °F ]
