Please review product documents or contact us for the latest agency approval information.

• Connector Product Type : Connector Assembly

• Prewired : Yes

• Assembly Type : Electrical Connector

• Connector System : Cable-to-Board

• Sealable : Yes

• Connector & Contact Terminates To : Printed Circuit Board

• Circular Connector Type : Receptacle

• Shell Type : Solder Mount Receptacle

• Factory Installed Backshell : Without

• Number of Positions : 6

• Number of Power Positions : 0

• Number of Signal Positions : 6

• Contacts Preloaded : Yes

• Durability Rating (Cycles): 2000

• Circuit Application : Signal

• Shielded : Yes

• Primary Product Color : Black

• Shell Plating Material : Black Zinc Nickel

• Shell Base Material : Aluminum 6061-T6

• Circular Connector Insulation Material Type : LCP (Liquid Crystal Polymer)

• Hermetically Sealed : No

• IP Water Sealing Level : IP67

• IP Dust Sealing Level : 5

• Operating Temperature Range : 0 – 70 °C [ 32 – 158 °F ]

• Position Locations Omitted : All

• Field Serviceable : No

• EU RoHS Compliance : Compliant with Exemptions

• EU ELV Compliance : Compliant with Exemptions

• Packaging Quantity : 1

• UL Flammability Rating : UL 94V-0

• Contact Current Rating (Max) (A): 1.5

• Reverse Gender : No

• Circular Connector Contact Type : Socket

• Polarization Code : Normal

• Mating Alignment Type : Keyed

• Mating Retention : With
