Please review product documents or contact us for the latest agency approval information.

Please Note: Use the Product Drawing for all design activity.

• Connector Shape : Rectangular

• Mixed & Hybrid Connector : Yes

• Connector & Housing Type : Housing for Female Terminals

• Connector System : Wire-to-Wire

• Sealable : Yes

• Primary Locking Feature : Integrated in Housing

• Connector & Contact Terminates To : Wire & Cable

• Contact Type : Receptacle

• Contact Size : 2.8mm, 1.5K

• Mating Tab Width (mm): 1.6, 2.8

• Mating Tab Width (in): .063, .11

• Contact Current Rating (Max) (A): 20, 32

• Housing Material : PBT GF30

• Centerline (Pitch) (mm): 4, 6

• Centerline (Pitch) (in): .157, .236

• Cable Exit Angle : 90°

• Primary Product Color : Blue

• Connector & Keying Code : C

• Serviceable : Yes

• Connector Position Assurance Capable : No

• EU RoHS Compliance : Compliant

• EU ELV Compliance : Compliant

• Mating Alignment : With

• Mating Alignment Type : Keyed

• Terminal Position Assurance : No

• Strain Relief : With

• Connector Mounting Type : Cable Mount (Free-Hanging)

• Packaging Method : Box

• Packaging Quantity : 180

• Connector Height : 42.5 mm [ 1.67 in ]

• Product Length : 69.7 mm [ 2.74 in ]

• Product Width : 37 mm [ 1.46 in ]

• Row-to-Row Spacing (mm): 5.5, 4

• Row-to-Row Spacing (in): .216, .157

• UL Flammability Rating : UL 94V-0

• IP Rating : IP69K, IP67

• Operating Voltage (VDC): 42

• Number of Positions : 22

• Number of Rows : 4, 3

• Operating Temperature (Max) : 120 °C [ 248 °F ]

• Operating Temperature Range : -40 – 120 °C [ -40 – 248 °F ]
