Please review product documents or contact us for the latest agency approval information.

Please Note: Use the Product Drawing for all design activity.

• Switch Connection Type : Wire Lugs

• Push Button Switch Product Type : General Purpose Push Button Switch

• Illuminated : Without

• Actuator Style : Cap - Order Separately

• Actuator Force : 400 – 2000 g [ 14.11 – 70.54 oz ]

• Product Orientation : Vertical

• Actuator Material : Nickel-Plated Copper Alloy

• Case Material : Thermoset

• Actuator Profile : Extended

• Bushing Style : Threaded

• Bushing Thread Size : 1/4-40

• Actuator Color : Natural

• Low Profile : No

• Process Sealed : No

• Contact Base Material : Silver Clad Copper

• Switch Contact Plating Material : Silver Clad with Gold Flash

• Actuator Length : 12.19 mm [ .48 in ]

• Bushing Length : 7.11 mm [ .28 in ]

• Packaging Method : Bulk

• Operating Temperature Range (°C): -20 – 85

• IP Rating : IP65

• Configuration (Pole-Throw) : Double Pole - Double Throw

• Number of Actuators : Single

• Snap Action : Without

• Support Bracket : Without

• Switch Feedback Type : Non-Tactile

• Operating Function : Momentary

• Contact Current Rating (A): 6

• Operating Voltage Range (VDC): 28

• Operating Voltage Range (VAC): 125, 250
