• Shell Material Configuration : Full Metal Shell

• Connector & Housing Type : Receptacle

• Connector System : Cable-to-Board

• Connector & Contact Terminates To : Printed Circuit Board

• Shell Material : Carbon Steel

• Housing Material : Thermoplastic

• Centerline (Pitch) : 1.27 mm [ .05 in ]

• Primary Product Color : Black

• Shell Plating Material : Tin over Copper

• Connector Profile : Standard

• PCB Mount Alignment : Without

• Mating Alignment : With

• Mating Alignment Type : Rails

• Mounting Hole Diameter : 2.77 mm [ .109 in ]

• Mounting Feature Material : Zinc

• Mounting Feature Plating Material : Nickel over Copper

• PCB Mount Retention : With

• PCB Mount Retention Type : Mounting Hole

• Mating Retention : With

• Mating Retention Type : Latches

• Connector Mounting Type : Board Mount

• PCB Contact Termination Area Plating Material : Tin

• Contact Base Material : Phosphor Bronze

• Contact Mating Area Plating Material : Gold or Gold Flash

• Contact Options : Installed

• Contact Mating Area Plating Material Thickness (µin): 30

• Contact Underplating Material : Palladium Nickel

• Contact Current Rating (Max) (A): 1

• Shielded : Yes

• Circuit Application : Signal

• Packaging Method : Tube

• Packaging Quantity : 7

• Square Termination Post & Tail Dimension : .38 mm [ .015 in ]

• Termination Post & Tail Length : 3.18 mm [ .125 in ]

• Termination Method to PCB : Through Hole - Solder

• UL Flammability Rating : UL 94V-0

• Number of Positions : 80

• Number of Rows : 4

• PCB Mount Orientation : Vertical

• Row-to-Row Spacing : 2.54 mm [ .1 in ]

• Operating Temperature Range : -55 – 105 °C [ -67 – 221 °F ]
