Please review product documents or contact us for the latest agency approval information.

• Connector & Contact Terminates To : Bus Bar

• Sealable : Yes

• Connector System : Bus Bar-to-Wire

• Header Type : Header & Push-Push Assembly

• Number of Positions : 1

• Number of Rows : 1

• Operating Voltage (VDC): 1000

• Nominal Voltage Architecture (V): 1000

• Operating Voltage (VAC): 1000

• Primary Product Color : Blue

• Connector & Keying Code : C

• Mating Pin Diameter : 14 mm [ .55 in ]

• Contact Mating Area Plating Material : Silver (Ag)

• Contact Type : Pin

• Connector Mounting Type : Panel Mount

• Mating Alignment Type : Polarization

• PCB Mount Alignment : Without

• PCB Mount Retention : Without

• Mating Alignment : With

• Operating Temperature Range : -40 – 140 °C [ -40 – 284 °F ]

• Operating Temperature (Max) : 140 °C [ 284 °F ]

• Circuit Application : Power

• IP Rating : IP6K9K

• UL Flammability Rating : UL 94V-0
