Please review product documents or contact us for the latest agency approval information.

Please Note: Use the Product Drawing for all design activity.

• Connector Shape : Rectangular

• Mixed & Hybrid Connector : No

• Connector & Housing Type : Housing for Female Terminals

• Connector System : Wire-to-Board, Wire-to-Device

• Sealable : No

• Primary Locking Feature : On the Terminal

• Connector & Contact Terminates To : Wire & Cable

• Contact Type : Receptacle

• Contact Size : 2.8mm

• Mating Tab Width : 2.8 mm [ .11 in ]

• Contact Current Rating (Max) (A): 30

• Housing Material : PA

• Centerline (Pitch) : 5 mm [ .197 in ]

• Cable Exit Angle : 180°

• Primary Product Color : Black

• Connector & Keying Code : Neutral

• Serviceable : Yes

• Connector Position Assurance Capable : No

• EU RoHS Compliance : Compliant

• EU ELV Compliance : Compliant

• Mating Alignment : With

• Mating Alignment Type : Polarized

• Terminal Position Assurance : No

• Connector Mounting Type : Cable Mount (Free-Hanging)

• Packaging Quantity : 400

• Packaging Method : Box

• Connector Height : 19.8 mm [ .779 in ]

• Product Length : 88.9 mm [ 3.498 in ]

• Row-to-Row Spacing : 5 mm [ .197 in ]

• Product Width : 27.4 mm [ 1.078 in ]

• Number of Positions : 25

• Number of Rows : 2

• Nominal Voltage Architecture (V): 24, 12

• Operating Temperature (Max) : 130 °C [ 266 °F ]

• Operating Temperature Range : -40 – 130 °C [ -40 – 266 °F ]
