Please review product documents or contact us for the latest agency approval information.

Please Note: Use the Product Drawing for all design activity.

• Connector Shape : Rectangular

• Mixed & Hybrid Connector : Yes

• Connector & Housing Type : Housing for Female Terminals

• Connector System : Wire-to-Wire

• Sealable : No

• Primary Locking Feature : Integrated in Housing

• Connector & Contact Terminates To : Wire & Cable

• Contact Type : Receptacle

• Contact Size : 1.8mm, 3mm

• Mating Tab Width (mm): 1.7, 2.8

• Mating Tab Width (in): .07, .11

• Housing Material : PBT

• Centerline (Pitch) (mm): 5.25, 3.5

• Centerline (Pitch) (in): .13, .2

• Cable Exit Angle : 180°

• Primary Product Color : Natural

• Serviceable : No

• Connector Position Assurance Capable : No

• EU RoHS Compliance : Compliant

• EU ELV Compliance : Compliant

• Mating Alignment : With

• Mating Alignment Type : Polarized

• Terminal Position Assurance : No

• Strain Relief : Without

• Connector Mounting Type : Cable Mount (Free-Hanging)

• Packaging Method : Bag

• Packaging Quantity : 300

• Connector Height : 21.9 mm [ .86 in ]

• Product Length : 22.6 mm [ .88 in ]

• Product Width : 22.8 mm [ .89 in ]

• Row-to-Row Spacing (mm): 5.53, 6.87

• Row-to-Row Spacing (in): .27, .21

• Number of Positions : 11

• Number of Rows : 3
