Please review product documents or contact us for the latest agency approval information.

Please Note: Use the Product Drawing for all design activity.

• Connector Shape : Rectangular

• Mixed & Hybrid Connector : No

• Connector & Housing Type : Housing for Female Terminals

• Connector System : Wire-to-Board, Wire-to-Device

• Sealable : Yes

• Primary Locking Feature : On the Terminal

• Connector & Contact Terminates To : Wire & Cable

• Contact Type : Receptacle

• Contact Size : 2.8mm

• Mating Tab Width : 2.8 mm [ .11 in ]

• Housing Material : PBT GF

• Centerline (Pitch) : 9.7 mm [ .382 in ]

• Cable Exit Angle : 180°

• Primary Product Color : Black

• Operating Voltage (VDC): 12

• Nominal Voltage Architecture (V): 12

• Serviceable : Yes

• Connector Position Assurance Capable : No

• EU RoHS Compliance : Compliant

• EU ELV Compliance : Compliant

• Mating Alignment : With

• Mating Alignment Type : Polarizing Slot

• Terminal Position Assurance : Yes

• Strain Relief : Without

• Connector Mounting Type : Cable Mount (Free-Hanging)

• Packaging Method : Box

• Connector Height : 26.5 mm [ 1.043 in ]

• Product Length : 30.7 mm [ 1.209 in ]

• Product Width : 33.8 mm [ 1.33 in ]

• UL Flammability Rating : UL 94HB

• Number of Positions : 2

• Number of Rows : 1

• Operating Temperature (Max) (°C): 125

• Operating Temperature (Max) (°F): 248, 221, 167, 158, 230, 176, 194, 185, 266, 212, 257

• Operating Temperature Range : -40 – 130 °C [ -40 – 266 °F ]
