Please review product documents or contact us for the latest agency approval information.

• Compatible With Wire & Cable Type : Discrete Wire

• Operating Voltage (VAC): 250

• Contact Diameter : 3.56 mm [ .14 in ]

• Contact Type : Socket

• Contact Mating Area Plating Material : Tin (Sn)

• Wire Contact Termination Area Plating Material : Pre-Tin

• Contact Retention Within Housing : With

• Contact Base Material : Copper Tin Alloy

• Contact Current Rating (Max) (A): 28

• Termination Method to Wire & Cable : Crimp

• Product Terminates To : Wire & Cable

• Contact Retention Type Within Housing : Locking Lance

• Compatible Insulation Diameter Range : 2.5 – 4.5 mm [ .098 – .177 in ]

• Wire Size (AWG): 20 – 14

• Wire Size (mm²): .5 – 2.1
