Please review product documents or contact us for the latest agency approval information.

Please Note: Use the Product Drawing for all design activity.

• Connector System : Wire-to-Board, Wire-to-Wire

• Sealable : No

• Connector & Contact Terminates To : Wire & Cable

• Connector & Housing Type : Receptacle

• Number of Positions : 1

• Primary Product Color : Black

• Terminal Type : Receptacle

• Terminal Orientation : Straight

• Contact Mating Retention : Without

• Mating Alignment Type : Polarization

• Mating Alignment : With

• Connector Mounting Type : Cable Mount (Free-Hanging)

• Housing Material : Polyamide

• Product Length : 24.4 mm [ .96 in ]

• Product Width (mm): 9.2

• Operating Temperature Range : -40 – 105 °C [ -40 – 221 °F ]

• UL Flammability Rating : UL 94V-2
