SMD Current Sense Metal Chip Resistor - Type TLMQ Series

The high power TLMQ series, an extension of the low ohmic metal chip resistor TLM series, is designed for current sensing circuits in power electronic systems which now also have a more advanced primary overcoat applied on both its top and bottom side offering higher reliability, accuracy and durability.

More Less

Product Features

Resistance Value (Ω): .01, .011, .012, .013, .015, .016, .018, .02, .022, .024, .027, .03, .033, .036, .039, .043, .047, .051, .056, .062, .068, .075, .082, .091, .1
Resistor Type : Current Sensing Resistor
Element Type : Foil
Package Size Code : 1206, 2010, 2512, 0603, 0805
Power Rating (W): .125, .5, .75, 1, 1.5, 2

Available from

Product	TE Part #	Documents	Package Size Code	Power Rating	Resistance Value	Temperature Coefficient	Product Height	Product Length	Product Width
TLM 0603 0.125W R082 1% 100PPM 5K RL	2-2176774-3	Product Drawing 3D PDF	0603	.125 W	.082 Ω	±100 ppm/°C	.5 mm	1.7 mm	1 mm
TLMQ 0805 0.75W R018 1% 50PPM 5K RL	2176776-7	Product Drawing 3D PDF	0805	.75 W	.018 Ω	±50 ppm/°C	.68 mm	2.15 mm	1.4 mm
TLMQ 0805 0.75W R022 1% 50PPM 5K RL	2176776-9	Product Drawing 3D PDF	0805	.75 W	.022 Ω	±50 ppm/°C	.62 mm	2.15 mm	1.4 mm
TLMQ 1206 1W R022 1% 50PPM 5K RL	2176777-9	Product Drawing 3D PDF	1206	1 W	.022 Ω	±50 ppm/°C	.62 mm	3.2 mm	1.7 mm
TLMQ 1206 1W R030 1% 50PPM 5K RL	1-2176777-2	Product Drawing 3D PDF	1206	1 W	.03 Ω	±50 ppm/°C	.62 mm	3.2 mm	1.7 mm
TLMQ 1206 1W R068 1% 50PPM 5K RL	2-2176777-1	Product Drawing 3D PDF	1206	1 W	.068 Ω	±50 ppm/°C	.62 mm	3.2 mm	1.7 mm
TLMQ 1206 1W R082 1% 50PPM 5K RL	2-2176777-3	Product Drawing 3D PDF	1206	1 W	.082 Ω	±50 ppm/°C	.62 mm	3.2 mm	1.7 mm
TLMQ 1206 1W R091 1% 50PPM 5K RL	2-2176777-4	Product Drawing 3D PDF	1206	1 W	.091 Ω	±50 ppm/°C	.62 mm	3.2 mm	1.7 mm
TLMQ 2010 1.5W R015 1% 50PPM 4K RL	2176778-5	Product Drawing 3D PDF	2010	1.5 W	.015 Ω	±50 ppm/°C	.68 mm	5 mm	2.5 mm
TLMQ 2010 1.5W R043 1% 50PPM 4K RL	1-2176778-6	Product Drawing 3D PDF	2010	1.5 W	.043 Ω	±50 ppm/°C	.62 mm	5 mm	2.5 mm
TLMQ 2010 1.5W R082 1% 50PPM 4K RL	2-2176778-3	Product Drawing 3D PDF	2010	1.5 W	.082 Ω	±50 ppm/°C	.62 mm	5 mm	2.5 mm
TLM 0603 0.125W R022 1% 100PPM 5K RL	2176774-9	Product Drawing 3D PDF	0603	.125 W	.022 Ω	±100 ppm/°C	.5 mm	1.7 mm	1 mm
TLMQ 0603 0.5W R015 1% 100PPM 5K RL	2176775-5	Product Drawing 3D PDF	0603	.5 W	.015 Ω	±100 ppm/°C	.55 mm	1.7 mm	1 mm
TLMQ 0603 0.5W R027 1% 100PPM 5K RL	1-2176775-1	Product Drawing 3D PDF	0603	.5 W	.027 Ω	±100 ppm/°C	.5 mm	1.7 mm	1 mm
TLMQ 0603 0.5W R10 1% 100PPM 5K RL	2-2176775-5	Product Drawing 3D PDF	0603	.5 W	.1 Ω	±100 ppm/°C	.5 mm	1.7 mm	1 mm
TLMQ 0805 0.75W R012 1% 50PPM 5K RL	2176776-3	Product Drawing 3D PDF	0805	.75 W	.012 Ω	±50 ppm/°C	.68 mm	2.15 mm	1.4 mm
TLMQ 0805 0.75W R051 1% 50PPM 5K RL	1-2176776-8	Product Drawing 3D PDF	0805	.75 W	.051 Ω	±50 ppm/°C	.62 mm	2.15 mm	1.4 mm
TLMQ 0805 0.75W R068 1% 50PPM 5K RL	2-2176776-1	Product Drawing 3D PDF	0805	.75 W	.068 Ω	±50 ppm/°C	.62 mm	2.15 mm	1.4 mm
TLMQ 0805 0.75W R075 1% 50PPM 5K RL	2-2176776-2	Product Drawing 3D PDF	0805	.75 W	.075 Ω	±50 ppm/°C	.62 mm	2.15 mm	1.4 mm
TLMQ 1206 1W R020 1% 50PPM 5K RL	2176777-8	Product Drawing 3D PDF	1206	1 W	.02 Ω	±50 ppm/°C	.62 mm	3.2 mm	1.7 mm
TLMQ 1206 1W R027 1% 50PPM 5K RL	1-2176777-1	Product Drawing 3D PDF	1206	1 W	.027 Ω	±50 ppm/°C	.62 mm	3.2 mm	1.7 mm
TLMQ 2010 1.5W R012 1% 50PPM 4K RL	2176778-3	Product Drawing 3D PDF	2010	1.5 W	.012 Ω	±50 ppm/°C	.68 mm	5 mm	2.5 mm
TLMQ 2512 2W R013 1% 50PPM 4K RL	2176779-4	Product Drawing 3D PDF	2512	2 W	.013 Ω	±50 ppm/°C	.68 mm	6.4 mm	3.2 mm
TLMQ 2512 2W R018 1% 50PPM 4K RL	2176779-7	Product Drawing 3D PDF	2512	2 W	.018 Ω	±50 ppm/°C	.68 mm	6.4 mm	3.2 mm
TLMQ 2512 2W R068 1% 50PPM 4K RL	2-2176779-1	Product Drawing 3D PDF	2512	2 W	.068 Ω	±50 ppm/°C	.62 mm	6.4 mm	3.2 mm
TLM 0603 0.125W R018 1% 100PPM 5K RL	2176774-7	Product Drawing 3D PDF	0603	.125 W	.018 Ω	±100 ppm/°C	.55 mm	1.7 mm	1 mm
TLM 0603 0.125W R020 1% 100PPM 5K RL	2176774-8	Product Drawing 3D PDF	0603	.125 W	.02 Ω	±100 ppm/°C	.5 mm	1.7 mm	1 mm
TLM 0603 0.125W R024 1% 100PPM 5K RL	1-2176774-0	Product Drawing 3D PDF	0603	.125 W	.024 Ω	±100 ppm/°C	.5 mm	1.7 mm	1 mm
TLM 0603 0.125W R027 1% 100PPM 5K RL	1-2176774-1	Product Drawing 3D PDF	0603	.125 W	.027 Ω	±100 ppm/°C	.5 mm	1.7 mm	1 mm
TLM 0603 0.125W R030 1% 100PPM 5K RL	1-2176774-2	Product Drawing 3D PDF	0603	.125 W	.03 Ω	±100 ppm/°C	.5 mm	1.7 mm	1 mm
TLM 0603 0.125W R036 1% 100PPM 5K RL	1-2176774-4	Product Drawing 3D PDF	0603	.125 W	.036 Ω	±100 ppm/°C	.5 mm	1.7 mm	1 mm
TLM 0603 0.125W R047 1% 100PPM 5K RL	1-2176774-7	Product Drawing 3D PDF	0603	.125 W	.047 Ω	±100 ppm/°C	.5 mm	1.7 mm	1 mm
TLM 0603 0.125W R056 1% 100PPM 5K RL	1-2176774-9	Product Drawing 3D PDF	0603	.125 W	.056 Ω	±100 ppm/°C	.5 mm	1.7 mm	1 mm
TLM 0603 0.125W R062 1% 100PPM 5K RL	2-2176774-0	Product Drawing 3D PDF	0603	.125 W	.062 Ω	±100 ppm/°C	.5 mm	1.7 mm	1 mm
TLMQ 0603 0.5W R011 1% 100PPM 5K RL	2176775-2	Product Drawing 3D PDF	0603	.5 W	.011 Ω	±100 ppm/°C	.55 mm	1.7 mm	1 mm
TLMQ 0603 0.5W R012 1% 100PPM 5K RL	2176775-3	Product Drawing 3D PDF	0603	.5 W	.012 Ω	±100 ppm/°C	.55 mm	1.7 mm	1 mm
TLMQ 0603 0.5W R016 1% 100PPM 5K RL	2176775-6	Product Drawing 3D PDF	0603	.5 W	.016 Ω	±100 ppm/°C	.55 mm	1.7 mm	1 mm
TLMQ 0603 0.5W R036 1% 100PPM 5K RL	1-2176775-4	Product Drawing 3D PDF	0603	.5 W	.036 Ω	±100 ppm/°C	.5 mm	1.7 mm	1 mm
TLMQ 0603 0.5W R047 1% 100PPM 5K RL	1-2176775-7	Product Drawing 3D PDF	0603	.5 W	.047 Ω	±100 ppm/°C	.5 mm	1.7 mm	1 mm
TLMQ 0603 0.5W R051 1% 100PPM 5K RL	1-2176775-8	Product Drawing 3D PDF	0603	.5 W	.051 Ω	±100 ppm/°C	.5 mm	1.7 mm	1 mm
TLMQ 0805 0.75W R033 1% 50PPM 5K RL	1-2176776-3	Product Drawing 3D PDF	0805	.75 W	.033 Ω	±50 ppm/°C	.62 mm	2.15 mm	1.4 mm
TLMQ 0603 0.5W R056 1% 100PPM 5K RL	1-2176775-9	Product Drawing 3D PDF	0603	.5 W	.056 Ω	±100 ppm/°C	.5 mm	1.7 mm	1 mm
TLMQ 0603 0.5W R075 1% 100PPM 5K RL	2-2176775-2	Product Drawing 3D PDF	0603	.5 W	.075 Ω	±100 ppm/°C	.5 mm	1.7 mm	1 mm
TLMQ 0603 0.5W R082 1% 100PPM 5K RL	2-2176775-3	Product Drawing 3D PDF	0603	.5 W	.082 Ω	±100 ppm/°C	.5 mm	1.7 mm	1 mm
TLMQ 0805 0.75W R062 1% 50PPM 5K RL	2-2176776-0	Product Drawing 3D PDF	0805	.75 W	.062 Ω	±50 ppm/°C	.62 mm	2.15 mm	1.4 mm
TLMQ 0603 0.5W R091 1% 100PPM 5K RL	2-2176775-4	Product Drawing 3D PDF	0603	.5 W	.091 Ω	±100 ppm/°C	.5 mm	1.7 mm	1 mm
TLMQ 0805 0.75W R082 1% 50PPM 5K RL	2-2176776-3	Product Drawing 3D PDF	0805	.75 W	.082 Ω	±50 ppm/°C	.62 mm	2.15 mm	1.4 mm
TLMQ 0805 0.75W R011 1% 50PPM 5K RL	2176776-2	Product Drawing 3D PDF	0805	.75 W	.011 Ω	±50 ppm/°C	.68 mm	2.15 mm	1.4 mm
TLMQ 1206 1W R010 1% 50PPM 5K RL	2176777-1	Product Drawing 3D PDF	1206	1 W	.01 Ω	±50 ppm/°C	.68 mm	3.2 mm	1.7 mm
TLMQ 1206 1W R013 1% 50PPM 5K RL	2176777-4	Product Drawing 3D PDF	1206	1 W	.013 Ω	±50 ppm/°C	.68 mm	3.2 mm	1.7 mm

Overview

SMD Current Sense Metal Chip Resistor

TE Connectivity (TE) has extended our low ohmic metal chip resistor TLM series with the High Power TLMQ. This series is designed for current sense circuits in power electronic systems which now also has a more advanced primary overcoat applied on both its top and bottom side which offers higher reliability, accuracy and durability. Supplied as standard on tape and reel for automatic insertion processes.

Features

Please review product documents or contact us for the latest agency approval information.

Product Type Features

Shelf Life 2 Years
Resistor Type Current Sensing Resistor
Element Type Foil
Package Size Code 1206, 2010, 2512, 0603, 0805

Configuration Features

Number of Resistors 1

Electrical Characteristics

Resistance Value (Ω) .01, .011, .012, .013, .015, .016, .018, .02, .022, .024, .027, .03, .033, .036, .039, .043, .047, .051, .056, .062, .068, .075, .082, .091, .1
Power Rating (W) .125, .5, .75, 1, 1.5, 2
Resistance Class Up to 1kΩ
Passive Component Tolerance (%) 1

Termination Features

Surface Mount Resistor Termination Type Solder
Number of Terminations 2

Dimensions

Product Height (mm) .5, .55, .62, .68
Product Height (in) .02, .022, .024, .027
Product Length (mm) 1.7, 2.15, 3.2, 5, 6.4
Product Length (in) .067, .085, .126, .197, .252
Product Width (mm) 1, 1.4, 1.7, 2.5, 3.2
Product Width (in) .039, .055, .067, .098, .126

Usage Conditions

Operating Temperature Range (°C) -55 – 155
Temperature Coefficient (ppm/°C) ±100, ±50

Industry Standards

UL Flammability Rating UL 94V-0
Industry Standard AEC-Q200 Compliant
ESD HBM Classification 2
Moisture Sensitivity Level 1

Packaging Features

Packaging Method Taped & Reeled

Reference Number

TE Internal Number CAT-LV3-TLM
