Please review product documents or contact us for the latest agency approval information.

Please Note: Use the Product Drawing for all design activity.

• Filler : PowerGel

• Power Component Options : Mechanical Connectors Included

• Tap Geometry : Parallel

• Cable Sealing Method : Gel

• Joints & Splices Connector Type : Connector Block

• Case Seal : Gel

• Joints & Splice Product Type : Inline Joint

• Closing Method : Snap to Close

• Compatible Cable Cross-Section - Branch (Max) (mm²): 16

• Compatible Cable Cross-Section - Branch (Min) (mm²): 2.5

• Compatible Cable Diameter - Main (Min) (mm): 14

• Compatible Cable Diameter - Branch (Min) (mm): 14

• Compatible Cable Diameter - Branch (Max) (mm): 25

• Compatible Conductor Cross-Section Range (mm²): 6 – 16

• Compatible Cable Cross-Section - Main (Max) (mm²): 16

• Compatible Cable Cross-Section - Main (Min) (mm²): 6

• Compatible Cable Diameter - Main (Max) (mm): 26

• Primary Product Color : Black

• Insulation Material : Polymeric

• Number of Branch Wires (Max) : 5

• Number of Main Wires (Max) : 5

• Product Use : Outdoor, Overhead & Direct Buried

• EU RoHS Compliance : Compliant

• EU ELV Compliance : Compliant

• Packaging Quantity : 1

• Packaging Method : Cardbox

• Fluid Resistance Type : Humic Acids, Water

• Operating Temperature Range (°C): -20 – 55

• Marine-Offshore-Shipbuilding Certified : No

• UV-Stabilized : Yes

• Compatible With Approved Standards Products : EN 50393

• Strain Relief : With

• Product Availability : China, Asia, Europe, Middle East & Africa, Australia, New Zealand & Pacific Islands, Americas
