Please review product documents or contact us for the latest agency approval information.

Please Note: Use the Product Drawing for all design activity.

• Connector Modification : Sealed Flange

• Number of Positions : 1

• Number of Rows : 1

• Connector Shape : Circular

• Mixed & Hybrid Connector : No

• Connector & Housing Type : Housing for Male Terminals

• Connector System : Wire-to-Wire

• Sealable : Yes

• Primary Locking Feature : Integrated in Housing

• Connector & Contact Terminates To : Wire & Cable

• Contact Type : Pin

• Contact Size : Size 4

• Mating Pin Diameter : 5.72 mm [ .225 in ]

• Contact Current Rating (Max) (A): 100

• Cable Exit Angle : 180°

• Primary Product Color : Black

• Operating Voltage (VDC): 250

• Operating Voltage (VAC): 250

• Nominal Voltage Architecture (V): 250

• Serviceable : Yes

• Connector Position Assurance Capable : No

• EU RoHS Compliance : Compliant

• EU ELV Compliance : Compliant

• Mating Alignment : With

• Mating Alignment Type : Polarized

• Terminal Position Assurance : No

• Strain Relief : With

• Connector Mounting Type : Panel Mount

• Packaging Method : Box

• Packaging Quantity : 160

• Connector Height : 43.18 mm [ 1.7 in ]

• Product Length : 52.53 mm [ 2.068 in ]

• Product Width : 57.15 mm [ 2.25 in ]

• Compatible Insulation Diameter Range : 6.63 – 10.67 mm [ .261 – .42 in ]

• UL Flammability Rating : Not tested

• IP Rating : Not Tested

• Housing Material : PEI (Polyetherimide)

• Operating Temperature (Max) : 125 °C [ 257 °F ]

• Operating Temperature Range : -55 – 125 °C [ -67 – 257 °F ]
