• Connector Seal Code : N Seal

• Blank Cavity Position : 0

• Number of Positions : 14

• Connector Shape : Circular

• Mixed & Hybrid Connector : Yes

• Connector & Housing Type : Housing for Female Terminals

• Connector System : Wire-to-Wire

• Sealable : Yes

• Primary Locking Feature : Contact Retainer

• Connector & Contact Terminates To : Wire & Cable

• Contact Type : Socket

• Contact Size : Size 16, Size 4, Size 12

• Mating Pin Diameter (mm): 2.39, 5.72, 1.59

• Mating Pin Diameter (in): .063, .225, .094

• Contact Current Rating (Max) (A): 100, 25, 13

• Operating Voltage (VDC): 250

• Operating Voltage (VAC): 250

• Nominal Voltage Architecture (V): 24, 12

• Serviceable : Yes

• Connector Position Assurance Capable : No

• EU RoHS Compliance : Compliant

• EU ELV Compliance : Compliant

• Mating Alignment : With

• Mating Alignment Type : Guide Post

• Terminal Position Assurance : No

• Strain Relief : Add By Accessory

• Connector Mounting Type : Panel Mount

• Packaging Method : Box

• Packaging Quantity : 80

• Connector Height : 47.53 mm [ 1.875 in ]

• Product Length : 84.28 mm [ 3.318 in ]

• Product Width : 50.8 mm [ 2 in ]

• Compatible Insulation Diameter Range (mm): 7.11 – 7.42, 2.54 – 3.4, 3.4 – 4.32

• Compatible Insulation Diameter Range (in): .1 – .134, .134 – .17, .28 – .292

• Cable Exit Angle : 180°

• Housing Material : Aluminum

• IP Rating : IP67

• Operating Temperature (Max) : 125 °C [ 257 °F ]

• Operating Temperature Range : -55 – 125 °C [ -67 – 257 °F ]
