Please review product documents or contact us for the latest agency approval information.

Please Note: Use the Product Drawing for all design activity.

• Connector Seal Code : N Seal

• Connector Modification : Ring Adapter

• Blank Cavity Position : 0

• Number of Positions : 33

• Connector Shape : Circular

• Mixed & Hybrid Connector : No

• Connector & Housing Type : Housing for Female Terminals

• Connector System : Wire-to-Panel

• Sealable : Yes

• Primary Locking Feature : Contact Retainer

• Connector & Contact Terminates To : Wire & Cable

• Contact Type : Socket

• Contact Size : Size 20

• Mating Pin Diameter : 1 mm [ .04 in ]

• Contact Current Rating (Max) (A): 7.5

• Cable Exit Angle : 180°

• Primary Product Color : Black

• Operating Voltage (VDC): 250

• Operating Voltage (VAC): 250

• Nominal Voltage Architecture (V): 250

• Serviceable : Yes

• Connector Position Assurance Capable : No

• EU RoHS Compliance : Compliant

• EU ELV Compliance : Compliant

• Mating Alignment : With

• Mating Alignment Type : Polarizing Slot

• Terminal Position Assurance : No

• Strain Relief : Without

• Connector Mounting Type : Panel Mount

• Packaging Method : Tray

• Packaging Quantity : 40

• Connector Height : 42.5 mm [ 1.67 in ]

• Product Length : 49.5 mm [ 1.95 in ]

• Product Width : 49.5 mm [ 1.95 in ]

• Compatible Insulation Diameter Range : 1.9 – 3.2 mm [ .075 – .125 in ]

• UL Flammability Rating : UL 94V-0

• IP Rating : IP67

• Housing Material : PA 66 GF

• Operating Temperature (Max) : 125 °C [ 257 °F ]

• Operating Temperature Range : -55 – 125 °C [ -67 – 257 °F ]
