ES-2002-T311-020B
Double Pole - Double Throw Configuration (Pole-Throw), Emergency Stop Switch, Single Actuator, KISSLING Series ES, Push Button Switches
ES-2002-T311-020B
Double Pole - Double Throw Configuration (Pole-Throw), Emergency Stop Switch, Single Actuator, KISSLING Series ES, Push Button Switches
-
- KISSLING
- KISSLING Series ES
- TE Internal #: K1160234
- TE Internal Description: Emergency Switch ES-2002-T311-020B
- All Emergency Stop Switch, 1 Actuator, Flush, Threaded Bushing (34)
-
Packaging Method : Bag
-
Actuator Force : 2040 – 5100 g [ 72 – 180 oz ]
-
Switch Contact Plating Material : Silver Alloy
-
Bushing Style : Threaded
-
Illuminated : Without
Documents
Product Drawings
- Emergency Switch Not-Halt Schalter ENG_CD_ES-2002-T311-020B_A.pdf English
CAD Files
-
Download ECAD Model File
Download the free Library Loader to convert this file to your ECAD Tool. Learn more about the ECAD Model.
- 3D PDF 3D_CVM_CVM_ES-2002-T311-020B_1.pdf 3D
- Customer View Model ENG_CVM_CVM_ES-2002-T311-020B_1.2d_dxf.zip English
- ENG_CVM_CVM_ES-2002-T311-020B_1.3d_igs.zip English
- ENG_CVM_CVM_ES-2002-T311-020B_1.3d_stp.zip English
Datasheets & Catalog Pages
- KISSLING E-STOP Series ES ENG_DS_K1166720_B.pdf English
