Please review product documents or contact us for the latest agency approval information.

Please Note: Use the Product Drawing for all design activity.

• Connector & Contact Terminates To : Bus Bar, Wire & Cable

• Connector & Housing Type : Housing for Male Terminals

• Primary Locking Feature : Integrated in Housing

• Sealable : Yes

• Connector Shape : Rectangular

• Connector System : Bus Bar-to-Wire

• Mixed & Hybrid Connector : No

• Number of Rows : 1

• Number of Positions : 2

• Connector Modification : (1) 2 Pin Buss

• Blank Cavity Position : 0

• Operating Voltage (VDC): 250

• Nominal Voltage Architecture (V): 250

• Operating Voltage (VAC): 250

• Primary Product Color : Black

• Mating Pin Diameter : 1.59 mm [ .063 in ]

• Contact Current Rating (Max) (A): 13

• Contact Type : Pin

• Connector Mounting Type : Bus Bar Mount

• Terminal Position Assurance : No

• Strain Relief : Add By Accessory

• Mating Alignment Type : Polarized

• Mating Alignment : With

• Centerline (Pitch) : 5.46 mm [ .215 in ]

• Housing Material : PA GF

• Product Width : 17.15 mm [ .675 in ]

• Connector Height : 17.02 mm [ .67 in ]

• Product Length : 46.18 mm [ 1.818 in ]

• Operating Temperature Range : -55 – 125 °C [ -67 – 257 °F ]

• Operating Temperature (Max) : 125 °C [ 257 °F ]

• Circuit Application : Power

• Compatible With Agency/Standards Products : SAE J2030

• UL Flammability Rating : Not tested

• Degree of Protection : IP6K9K, IP68

• Packaging Method : Box

• Packaging Quantity : 950
