SUPERSEAL pro Inline Sealed Connector

Our SUPERSEAL pro connector provides a high-value solution for chassis applications. It is specially designed to deliver better reliability and boost performance in sealed inline applications for industrial and commercial vehicles operating in harsh environments.

Using the MCON 1.2 SWS terminal with a 17A- current-carrying capacity, SUPERSEAL pro 2-,3-, and 4- position sealed connectors provide a vibration resistance that complies with USCAR V2. With pre-assembled and color-coded TPA options, SUPERSEAL pro’s integrated front seal housing design improves terminal retention and allows easy assembly with proper terminal positioning during mating and un-mating made with flame-retardant UL 94 V-0 materials with the optional HB for a sealing level of IP67, IP68 and IP6K9K (with back shell), SUPERSEAL pro connectors offer high protection and superior sealing performance, enabling water-tight connections. SUPERSEAL pro’s wire-to-wire application delivers better reliability, great resistance to water and moisture and increased performance in sealed inline applications, whilst offering more cost-effective choices for commercial vehicle.

Product Features

Contact System MCON 1.2 SWS
Current Rating Up to 17 amps (80°C)
Degree of Protection IP67,IP68 and IP6K9K(with back shell)
Vibration Resistance In Compliance with USCAR V2
Maximum Voltage 12V/24V DC
Operating Temperature -40°C - +125°C
Flammability UL 94 V-0 Material

Key Benefits

Dependability

  • Enhance vibration resistance level with time-tested MCON 1.2 SWS terminal in compliance with USCAR V2
  • Additional safety and better flammability protection with UL 94 V-0 materials and the optional HB
  • High level of protection with enhanced seal retention features



Ease of Assembly

  • Eliminate additional assembly with TPA pre-lock and enhanced front seal
  • Prevent mis-mating of connectors with four coding options and colors



One-stop Service

  • Provide one-stop service with a wide range of accessories
Light Duty Truck

Light Duty Truck

BUS

Bus

Heavy-Duty_Truck

Heavy-Duty Truck

2-Wheeler

2-Wheeler

Industrial

Industrial

Appliances

Appliances

Wire 2 Wire

Wire 2 Wire

Sensor

Sensor

Lights

Lights

Gauges

Gauges

Actuators

Actuators

Switches

Switches

SUPERSEAL pro Inline Connectors

Our SUPERSEAL pro connector provides a high-value solution for lower-vibration chassis applications specially designed to deliver better reliability and boost performance in sealed inline applications for industry and commercial vehicles operating in harsh environments.

SUPERSEAL pro Inline Connectors

Our SUPERSEAL pro connector provides a high-value solution for lower-vibration chassis applications specially designed to deliver better reliability and boost performance in sealed inline applications for industry and commercial vehicles operating in harsh environments.

Frequently Asked Questions

Q: What is a SUPERSEAL pro inline connector?

A:  TE Connectivity’s SUPERSEAL pro inline connector is a new generation sealed inline connector built based on USCAR technical specification for lower vibration chassis application. The Superseal pro inline connectors are used in harsh environment applications where a high vibration-resistant performance  is required.

Q:What are the appropriate applications for SUPERSEAL pro inline connectors?

A:  SUPERSEAL pro inline connectors are ideally suited for light-duty truck and bus market customers, and can be applied to various fields such as on-road vehicles and off-road vehicles (construction, agriculture, etc).

Q: When can SUPERSEAL pro inline connectors be used?

A:SUPERSEAL pro inline connectors can be used for wire-to-wire connectivity in engine, chassis, cab, automation, lighting, diagnostic uses.



READ MORE FAQs about SUPERSEAL pro Inline Sealed Connector
