Blind Mating Mobile Charging Connector

Blind mating mobile charging connector for smaller mobile robots and autonomous vehicles

Our blind mating mobile charging connector is intended for smaller mobile robots and autonomous vehicles typically used in warehouse environments. Autonomous Mobile Robots (AMR) are currently used mostly for material handling (picking, movement, storage, sorting) in the warehouse automation space. The charging connector is available in 2 and 3 power contact options with up to 8 signal contacts to ease installation and rework cycle times.

Connect with us

Download Now

Request free samples of TE products to test in your designs.

Order Samples

Product Benefits

High mating cycle life
Modular solution that will support different configurations, data, sensing
First make last break power contact (3P only)
Floating panel mount design maximizes misalignment tolerance capability
UL recognized to UL 1977

Product Features

Robust Design for High Cycle Life

Designed for a minimum of 12,000 mating cycles
Low insertion force power contacts
Spring probe signal contacts
Blind mate capability
Allows for misalignment of at least +/-15mm for x and +/- 10 for y direction
+/- approx. 5° for z direction (mating)

Connection Flexibility

2 & 3 power contact options
Up to 50A and up to 125V
Up to 40A per line at up to 100V
Terminates to 10 or 8 AWG stranded copper wire
First make, last break contact for use in grounding, system enabling or applications that require charging two battery strings independently
Touch safe contacts for extra safety if the rework is needed

Up to 8 signal contacts

Up to 0.5A per line
Terminates to 22-30 AWG stranded wire
Rear pluggable interface to ease installation and rework cycle times
Spring probe contacts for high cycle life
Utilizes Mini Universal MATE-N-LOKII Connector interface for signal contact mating

AMR Blind Mating Mobile Charging Connector
