Electrical Vehicle Charging

The reliable and compact power latching relays with 60-120Amp switching capablity is designed to support the demand for higher switching capability in power distribution applications. It is energy-saving and provides low self-heating.

T92 series two-pole 50A relay provides improved ratings and enables usage in higher power and extreme temperature environments in charging applications.

T9V series enables high current switching by improved isolation. Designed to withstand in high temperature up to 105C and EN 61851 and AEC-Q200 qualified  makes it an ideal solution for 6.6kw~11kw AC charging stations and also for on-board chargers.

The 16A power relay provides high electrical switching capability and is designed to withstand high ambient temperature up to 105C. It is AEC-Q200 qualified and a reliable and effective solution for low power on-board chargers with the enhanced productivity.

ECK series (NO-DM) high-voltage DC contactor is designed for control in new energy applications. They are hermetically sealed and enable high switching voltage up to 1000VDC.

The ECP contactors arehermetically sealed with ceramic technology. The main contact chamber, filled with hydrogen gas, significantly enhances the contactor's high-performance electrical endurance. They enable high switching voltage up to 1500 VDC.

Super compact and highly reliable, designed for high retention force and proven performance in harsh and vibration environment. Specially designed shrink surface to help prevent risk of mis-matching.

Engineered to safely transmit signal in the harsh environment with a broader position ranges from 2 to 40, gold and tin plating options to meet various needs. Highly reliable and compact design to fit for Electric Vehicle market.

Cost effective, reliable, enhanced productivity, and a unique design of 3-point contact to withstand extreme vibration. It's also a safer choice empowered by the high-level anti-flash housing material.

Designed for a safer and reliable power connection which can carry up to 45A current with silver plated contacts.

AMPMODU 2 mm connectors support automated surface-mount, through-hole reflow (Pin-in-Paste), and traditional through-hole mount processes for ease of manufacturing.​

A family of board-to-board fine pitch connectors with a .050" x .050" (1.00 mm x 1.00 mm) centerline, with 85% space savings on the board and offers greater flexibility in board assembly.

Coupling shrouds permit ganging of receptacle assemblies for dual-row configurations. They are available in IDC and crimp termination types while their latching capability provides positive retention between housings.

Micro-MaTch connectors provide a proven reliable connection. Its unique contact-spring system help prevent fretting corrosion by absorbing movements between male and female contacts.

The MaxiBridge connector system is ideally suited for space-saving, highly stressed connections such as those found in modern vehicles. The single- and double-row cable connector system has a high current rating of up to 12 A per contact.

The first-class processed, robust SMC connectors with a small grid of 1.27 mm enable compact, safe and reliable connections with a high current rating and outstanding signal integrity. Data rates up to 3 Gbit/s are possible.

High currents can be transmitted to PCBs with ERNI PowerElements. They are available for contacting via pressfit technology or SMD solder technology. They enable the wire-to-board supply of high current ratings up to 360 A between PCBs.

HS series, the aluminum housed resistor, is a range of extremely stable, high quality wire wound resistors capable of dissipating high power in a limited space with relatively low surface temperature.

SQ series resistors are wound or deposited on a fine non - alkali ceramic core design, which provides a resistor with high insulation resistance, low surface temperature, excellent T.C.R., and entirely fireproof construction.

AV series, the Anti-Vandal switch, is designed for security and reliability in a variety of applications. AV Switches are sealed to IP67 and available in single and double pole configurations

The PBES16 Series Pushbutton Emergency Stop Switch is offered as an Illuminated and Non-Illuminated switch. This series has multiple lighting options, agency approvals, and meets IEC 60947-5-1 & IEC 60947-5-5 standards.

Corcom EMI filters help control electromagnetic interference (EMI) signal issues in industrial applications and save space with a compact design.

3-Phase filters reduce unwanted electromagnetic interference (EMI) noise within the conducted area of electromagnetic susceptibility. TE’s Corcom portfolio of 3-phase filters includes an operating current range of 3 to 1600 A, with operating voltages from 250VAC to 520VAC.

The EVX filters are state of the art design with three high voltage levels (500 V, 1000 V, 1500 V) and current rating from 150A up to 1600 A. They are designed to handle high power from 75 kW to 2.4 MW.

Innovative product families share rich accessories, including PI (in-line)-spring connection (compatible with both in-line and spring styles), screwed wire-pressing frame connection and plug-in connection that meet the needs of various EV charging applications.

DBL distribution blocks are engineered with an exclusive compact and modular design allowing easy installation combined with a great flexibility of use.

TE SOLISTRAND terminals and splices are specifically engineered to ensure reliable and long-lasting performance in the harsh environments.

PIDG terminals and splices (Pre-Insulated Diamond Grip) are designed for complete and uniform reliability in the difficult circuit environments.

The cable glands provide excellent strain relief for cables and high ingress protection against dirt, dust, water and other liquids for electrical enclosures.

The wiring duct range includes popular profile widths such as 24, 40, 60, 80 100 and 120 mm. The high-quality PVC & halogen free material allows the use in many applications.

Identification Solutions Heat shrinkable Tubing for wire and cable identification made from flame retardant, cross-lined polyolefin material.
