Connector, Not Rotatable, Wire-to-Component, 5 Position, Sealable, Power & Signal, LUMAWISE Dimming Receptacle, ANSI Street Lighting Receptacles
1-2213362-3
Connector, Not Rotatable, Wire-to-Component, 5 Position, Sealable, Power & Signal, LUMAWISE Dimming Receptacle, ANSI Street Lighting Receptacles
-
- LUMAWISE
- LUMAWISE Dimming Receptacle
- TE Internal #: 1-2213362-3
- TE Internal Description: Rcpt Assy,Dimmable Photocontrol,105C,3/2
- All LUMAWISE Endurance N Poke-In: Streetlight Dimming Receptacles (36)
-
Operating Temperature Range : -40 – 85 °C [ -40 – 185 °F ]
-
Primary Product Color : Black
-
Connector & Contact Terminates To : Wire & Cable
-
Wire Size (AWG): 18 – 14
-
Lighting Connector Features Included : Not Rotatable
