Please review product documents or contact us for the latest agency approval information.

Please Note: Use the Product Drawing for all design activity.

• Connector Shape : Rectangular

• Mixed & Hybrid Connector : Yes

• Connector & Housing Type : Housing for Male Terminals

• Connector System : Wire-to-Wire

• Sealable : Yes

• Primary Locking Feature : On the Terminal

• Connector & Contact Terminates To : Wire & Cable

• Contact Type : Tab

• Contact Size : 2.8mm, 1.6mm

• Mating Tab Width (mm): 1.6, 2.8

• Mating Tab Width (in): .063, .11

• Contact Current Rating (Max) (A): 30, 10

• Housing Material : PBT GF20

• Centerline (Pitch) (mm): 4, 5

• Centerline (Pitch) (in): .157, .197

• Cable Exit Angle : 90°

• Primary Product Color : Gray

• Connector & Keying Code : B

• Serviceable : Yes

• Connector Position Assurance Capable : No

• EU RoHS Compliance : Compliant

• EU ELV Compliance : Compliant

• Mating Alignment : With

• Mating Alignment Type : Keyed

• Terminal Position Assurance : Yes

• Strain Relief : With

• Connector Mounting Type : Panel Mount

• Packaging Method : Box

• Packaging Quantity : 80

• Connector Height : 45.8 mm [ 1.803 in ]

• Product Length : 113.25 mm [ 4.459 in ]

• Product Width : 70.7 mm [ 2.783 in ]

• Row-to-Row Spacing : 1.5 mm [ .059 in ]

• UL Flammability Rating : UL 94HB

• IP Rating : IP69K, IP67

• Operating Voltage (VDC): 36

• Number of Positions : 62

• Number of Rows : 4, 3

• Operating Temperature (Max) : 120 °C [ 248 °F ]

• Operating Temperature Range : -40 – 120 °C [ -40 – 248 °F ]
