• Connector Product Type : Housing

• Connector & Housing Type : Plug

• Connector System : Wire-to-Board

• Sealable : No

• Connector & Contact Terminates To : Wire & Cable

• Number of Signal Positions : 2

• Number of Power Positions : 2

• Number of Positions : 2

• Number of Rows : 1

• Operating Voltage (VDC): 300

• Operating Voltage (VAC): 300

• Primary Product Color : Natural

• Contact Mating Area Plating Material Thickness : .8 µm [ 31.5 µin ]

• Contact Type : Receptacle

• Contact Mating Area Plating Material : Tin (Sn)

• Contact Retention Within Housing : With

• Contact Current Rating (Max) (A): 10

• Termination Method to Wire & Cable : Crimp

• Connector Mounting Type : Board Mount

• Housing Material : Nylon 6/6 GF

• Centerline (Pitch) : 6 mm [ .236 in ]

• Wire Size (AWG): 24 – 16

• Wire Size (mm²): .22 – 1.38

• Wire Size (CMA): 434.2 – 2723.5

• Operating Temperature Range : -40 – 105 °C [ -40 – 221 °F ]

• Circuit Application : Power & Signal

• Glow Wire Rating : GWT 750°C (Without Flame)

• UL Flammability Rating : UL 94V-0
