Please review product documents or contact us for the latest agency approval information.

Please Note: Use the Product Drawing for all design activity.

• Coating Style : Spiral, Planar

• Installation Technology : Heat Shrink

• Adhesive Coating : With

• Compatible Cable Diameter - Body (Max) : 32 mm [ 1.259 in ]

• Wall Thickness : Thick/Heavy

• Recovered Wall Thickness (Max) (Body) (mm): 3.2

• Compatible Cable Diameter - Body (Min) : 16.5 mm [ .649 in ]

• Expanded Inside Diameter (Min) (mm): 35

• Recovered Inside Diameter (Max) (mm): 15

• Recovered Overall Length (mm): 90

• Primary Product Material : Crosslinked Polyolefin

• Primary Product Color : Black

• Shrink Ratio : > 2:1

• Flexibility : Semi-Rigid

• Environmental Resistance : Salt Water, Weathering, Contaminated Water, Rain, Moisture

• Fluid Resistance Type : Hydrocarbons

• Flammability Performance : Non-Flame-Retardant

• Marine-Offshore-Shipbuilding Certified : Yes

• UV-Stabilized : Yes

• Mechanical Resistance : Against Mechanical Impact

• Compatible With Approved Standards Products : HD631.2, IEC 62329-3

• Compatible With Agency/Standards Products : UL, CSA

• Voltage Class (kV): ≤ 1

• Product Availability : Americas
