Overview
ALROC Cable Preparation Tooling
- ALROC
- ALROC CWB ,
- ALROC LHA ,
- ALROC DSP ,
- ALROC CWE
Product Features
-
Product Availability : Americas
-
Product Weight (kg): 2.27, 3.86, .84, .87, 1.85, .45, .51, .01, .02
Utilizing dedicated cable preparation tools can help to mitigate the risk of failures due to improper cable preparation procedures.
We understand the importance of listening to existing problems and preventing new ones to come, that is why we are proud to offer the ALROC line of specialized cable preparation tools, which are designed to assist with all aspects of cable preparation, from jacket/sheath removal and semicon scoring, to insulation stripping and chamfering.
The ALROC cable preparation tooling line helps ensure a safe – and repeatable – cable preparation process for low and medium voltage cables.
ALROC is constantly investing in new production methods and innovating technologies, with a long know-how in the metal working, mould design, gravity cast makes of ALROC a recognized specialist in the alloy transformation. Safety and precision are their two principles, which they put into actions on its will to reduce their environmental footprint. For more than 30 years, ALROC has been engineering, designing and manufacturing cable preparation tools and cable fixing solutions to establish the most complete product range covering different areas such as LV cable, MV cable among others.
The ALROC CWF Series multifunction tool enables the user to remove the outer sheath (PE-PVC-PR) with a straight and neat cut, to score the peelable semiconductor with a chamfer on the edge of the semiconductor cutback (with the SRC scoring stylus delivered with the tool). And to set the length to be removed and remove thicker insulation with a straight and neat cut. Discover how.
Key Features
- Heavy-duty build has been proven in the market for over 30 years.
- Fast and efficient use results in clean and precise preparation.
- Versatile products intuitive use
- Mono-functional and Multi-functional tools.
- Professional build quality.
- European built.
- Easily changed spare parts.
- Design and development over the past 30 years of tools serving global markets.
- Easy and fast installation thanks to the engineered design.
- Available with stainless-steel hardware for higher corrosion resistance and mechanical performance.
ALROC Cable Preparation Tooling
Improving Grid Connectivity
Know More
-
Power Connector Tools
Product Listing Page
-
Power System Connectors
Product Family Group
Frequently Asked Questions
Question: Are ALROC’s blades and other parts changeable?
Answer: Yes, most ALROC’s part are easy to change, and they are
readily available.
Question: Can ALROC customize the depth of the blades?
Answer: Yes, on most tools ALROC have many depths available to fit your needs. ALROC can also develop specific requests based upon volumes.
Question: What are the materials that ALROC use?
Answer: ALROC uses mostly Aluminum and cupro-aluminum that goes thru various hardening treatment increasing its wear resistance and making them highly resistant to corrosion and cavitation. Brass is also used as well as PVC for the coating and polymer used in our injected parts.
Question: Where are ALROC’s tools made?
Answer: ALROC’s tools are made in France. Most of every component is manufactured by the same company or sister companies. +90% starts from raw material that has been melted, injected or machined with minimal external intervention.
Question: Are ALROC’s tools insulated?
Answer: ALROC do provide ASTM 1505 insulated tools to strip the lead jacket and a few low voltage strippers. However, most of ALROC’s low voltage and ALL medium and high voltage tools are not insulated in any way.
Question: Do ALROC’s tools need training?
Answer: Yes, ALROC do recommend users to be trained to maximize the result of the cable prep work. The tools are quite self-understanding, but a short training will make any user an expert with a high degree of precision.
Question: Does the ALROC tool meet any standard?
Answer: ALROC has a few tools that meet the ASTM 1505 standard, but otherwise the market, in general, does not require tools to meet any standards.
Question: How long have ALROC’s tools existed?
Answer: ALROC has been successfully manufacturing stripping tools for the past 40+ years.
Question: Where has ALROC tools been used in the past?
Answer: During its past 40+ years in business, ALROC has sold tools on every continent and almost every country. ALROC has been a leader in markets such as France, Germany, UK, Spain, Malaysia, Mexico, Algeria, Moroco, Tunisia, Canada, Finland etc…
Question: Does ALROC has new tools coming out?
Answer: ALROC tries to bring new tools to the market every year. Please keep us informed of your needs and we will help you make your job easier!
Please review product documents or contact us for the latest agency approval information.
Operation/Application
-
Power Component Application Type Underground
Electrical Characteristics
-
Voltage Class (kV) ≤ 500
Product Availability
-
Product Availability Americas
Dimensions
-
Product Weight (kg) 2.27, 3.86, .84, .87, 1.85, .45, .51, .01, .02
Reference Number
-
TE Internal Number CAT-ALROC-TOOLING
Datasheets & Catalog Pages
- CABLE PREPARATION TOOLING English
