08-2-2-25 955
Double Pole - Double Throw Configuration (Pole-Throw), On On (On), 3 Position, Operating Voltage 28 VDC, Operating Voltage 115 VAC, KISSLING Series 08
08-2-2-25 955
Double Pole - Double Throw Configuration (Pole-Throw), On On (On), 3 Position, Operating Voltage 28 VDC, Operating Voltage 115 VAC, KISSLING Series 08
-
- KISSLING
- KISSLING Series 08
- TE Internal #: K1143604
- TE Internal Description: Toggle Switch 08-2-2-25 955
- All Toggle Switch 2-Pole, Sealed, Lever, Toggle, Plastic Lever (38)
-
Configuration (Pole-Throw) : Double Pole - Double Throw
-
Operating Function : On On (On)
-
Number of Positions : 3
-
Operating Voltage (VDC): 28
-
Operating Voltage (VAC): 115
