2-Year TE Installer Certification for Raychem High Voltage Cable Accessories (HVCA)

Register Here
*Required fields

Your Information

BECOME A RAYCHEM HVCA CERTIFIED INSTALLER

Gain the technical knowledge and practical skills to successfully and safely install selected Raychem HVCA products from TE Connectivity, ranging from 72 kV to 245 kV. Our installer certification is valid for two years depending upon your course selection. Courses cover dry terminations, compact pluggable switchgear terminations, inline and shield break joints.



The training includes:

• Overview of our product design specifications

• Review of our product installation instructions

• Installation techniques and methods

• Cable preparation assessment

• Identification of installation errors



YOUR BENEFITS

• Increased grid reliability thanks to our experts' installer practices and trainer knowledge

• Installation consulting support during your 2-year certificate

• Stay up to date with the latest product updates and innovations



OUR TRAINING CONTENT

In English or German.

DATE   OVERVIEW

Day 1

• Product overview presentation

• Raychem HVCA product and tools introduction

• Preparation for installation

• Tools and cable preparation

• Familiarization with different screen types

Day 2

• Installation of our Raychem EHVS HV joint

Day 3

• Installation of our Raychem OHVT HV termination

Day 4

• Installation of our Raychem PHVX HV switchgear termination

Day 5

• Final installation and examination

• Assessment and feedback with Question & Answer session

5-DAY COURSES
AUTUMN 2022

8 Participants Maximum per Course

We can tailor 5-day courses for a certification on 3 products or organize trainings at a more convenient date on demand.



DATE COURSE NUMBER STATUS

10.10 - 14.10.2022

TEHV2141

Full

24.10 - 28.10.2022

TEHV2143

Full

07.11 - 11.11.2022

TEHV2145

Full

28.11 - 02.12.2022

TEHV2148

Full

05.12 - 09.12.2022

TEHV2149

Full



TRAINING PREREQUISITES

• You are an installer or jointer of HVCA cable accessories

• You have 1+ years of HVCA product installation experience, including HV cable preparation, system extension, connection, refurbishment, maintenance and repairs

• You are required to provide TE with a cable preparation certificate before registration



TOOLS REQUIRED

Participants must bring:

• Appropriate PPE equipment including overalls, safety shoes or boots, and gloves

• Appropriate hand tools



High Voltage installation tools are provided.

HV CABLE AND ACCESSORIES

Standard cable and accessories will be used:

• 500 to 800 mm2 cable Al/Cu with Cu wire and Al foil



If you need a different or customized cable type to be used in the training session, please contact our training center manager to arrange.

LOCATION AND STAY

Find the directions to reach our Training Center in Ottobrunn, Germany HERE.



We can recommend some hotels near our training center: HOTEL LIST
