Please review product documents or contact us for the latest agency approval information.

Please Note: Use the Product Drawing for all design activity.

• Housing Entry Configuration : Both Ends Closed

• Housing Material : PA 66 GF

• Centerline (Pitch) : 2.5 mm [ .098 in ]

• Connector & Keying Code : A

• Primary Product Color : Natural

• PCB Mount Retention : Without

• Mating Retention Type : Latch

• Panel Mount Feature : Without

• Strain Relief : Without

• Mating Retention : With

• Connector Mounting Type : Cable Mount (Free-Hanging)

• Contact Type : Tab

• Contact Base Material : Copper Alloy

• Contact Retention Within Housing : Without

• Contact Layout : Inline

• Contact Current Rating (Max) (A): 3

• Wire Size (AWG): 28 – 22

• Wire Size (mm²): .081 – .326

• Connector Length (in): .224

• Connector Height : 5.88 mm [ .231 in ]

• Packaging Quantity : 400

• Packaging Method : Bag & Box

• Glow Wire Rating : Glow Wire

• UL Flammability Rating : UL 94V-0

• Operating Voltage (VDC): 50

• Operating Voltage (VAC): 50

• Connector Product Type : Housing

• Connector & Housing Type : Plug

• Connector System : Wire-to-Wire

• Sealable : No

• Connector & Contact Terminates To : Wire & Cable

• Number of Positions : 2

• Number of Rows : 1

• Termination Method to Wire & Cable : Crimp

• Operating Temperature Range : -30 – 105 °C [ -22 – 221 °F ]

• Circuit Application : Power & Signal
