Inline Joint: Cold Shrink for JCN Cables 15-35 kV
Product Features
-
Product Availability : Americas
-
Installation Instruction : English
-
Joints & Splice Product Type : Inline Joint, Medium Voltage Inline Joint
-
Voltage Class (kV): ≤ 15, ≤ 35, ≤ 28
-
Compatible Conductor Range (AWG/kcmil): 2 – 3/0, 750 – 1250, 4/0 – 750, 2 – 350, 350 – 1000, 750 – 1000, 500 – 1250, 4/0 – 500, 2/0 – 350, 350 – 750, 1 – 500, 1000 – 1250, 1/0 – 350, 1 – 350
Our Raychem CSJA-JCN Cold Shrink Joints are an “All-in-One” solution. They bring the cable’s concentric neutral wires outside of the splice and connect them at a single point to ensure full neutral ampacity is maintained. The joint body is made of silicone rubber that provides high dielectric strength, high tear strength, low tension set, and good low-temperature recovery. These Cold Shrink Joints have an integrated stress control enhanced by factory molded stress cones and a Faraday cage. They are compatible with both mechanical and compression connectors and no void-filling stress relief mastics are necessary. Each silicone splice body is factory tested to include AC withstand and partial discharge in accordance with IEEE 404.
Key Features
- Pre-expanded EPDM rejacketing sleeve and integrated neutral sock
- Compact design: total length of splice body on holdout from 14 to 19 inches
- Pre-expanded, single piece silicone rubber joint body with high mechanical expansion capability for wide application range
- Ergonomically designed spiral holdout for smooth installation
Cold Shrink Joint
Improving Grid Reliability
Our Power Cable Terminations
Frequently Asked Questions
Question: What are the primary applications of TE’s Raychem Cold Shrink Splice CSJA-JCN?
Answer: Our Raychem Cold Shrink Splice CSJA-JCN is a single-core joint for jacketed concentric neutral (JCN) cables in underground applications.
Question: With what type of cable conductor can I use the Cold Shrink Splice CSJA-JCN?
Answer: These splices can be used with aluminum or copper stranded, compact, compressed, or solid round conductor.
Question: What are Cold Shrink Splices for JCN Cables made of?
Answer: The joint / splice body is made of Liquid Silicone Rubber (LSR) which provides high dielectric strength, high tear strength, low tension set, and excellent low temperature recovery. It has integrated stress control, enhanced by factory molded stress cones and a Faraday cage.
Question: What voltage range do Cold Shrink Splices for JCN Cables cover?
Answer: These slices / joints are qualified up to 42 kV by CENELEC HD 629.1, and up to 35 kV by IEEE 404.
Question: Can I use crimp connectors with the Cold Shrink Splices for JCN Cables?
Answer: Yes, both mechanical and compression connectors can be used with our Raychem Cold Shrink Splices for JCN Cables.
Question: With which standards are Cold Shrink Splices for JCN Cables compliant?
Answer: These splices / joints are qualified by CENELEC HD 629.1 and they are tested to IEEE 404.
Please review product documents or contact us for the latest agency approval information.
Packaging Features
-
Packaging Method Cardbox
-
Packaging Quantity 1
Product Type Features
-
Shelf Life 2 Years
-
Cable Sealing Method Mastic
-
Power Component Options Mechanical Connectors Included
-
Material System Silicone
-
Adhesive Coating Without
-
Coating Style Painting
-
Installation Technology Cold Shrink, Cold Applied
-
Joints & Splices Connector Type Mechanical
-
Joints & Splice Product Type Inline Joint, Medium Voltage Inline Joint
-
Cable Shield Style JCN
Dimensions
-
Length (Installed) (mm) 737, 939, 838
-
Length (Installed) (in) 33, 29, 37
-
Compatible Conductor Range (AWG/kcmil) 2 – 3/0, 750 – 1250, 4/0 – 750, 2 – 350, 350 – 1000, 750 – 1000, 500 – 1250, 4/0 – 500, 2/0 – 350, 350 – 750, 1 – 500, 1000 – 1250, 1/0 – 350, 1 – 350
-
Compatible Insulation Diameter Range (mm) 26.2 – 40, 34.5 – 52, 22.1 – 35.6, 26.2 – 37.8, 17.5 – 30.5, 32.5 – 52, 41.4 – 60
-
Compatible Insulation Diameter Range (in) 1.28 – 2.05, 1.36 – 2.05, .87 – 1.4, 1.63 – 2.36, .69 – 1.2, 1.03 – 1.58, 1.03 – 1.49
-
Compatible Conductor Diameter Range (mm) 7.41 – 11.93, 13.41 – 25.34, 17.3 – 25.34, 17.3 – 29.3, 20.65 – 32.74, 20.6 – 29.2, 13.41 – 20.65, 10.61 – 17.3, 25.34 – 29.3, 30.9 – 35.3, 25.34 – 32.74, 8.43 – 20.65, 23. – 31.7, 8.43 – 25.34, 25.4 – 32.74, 29.3 – 32.74, 9.5 – 17.3, 7.41 – 25.34
-
Compatible Conductor Diameter Range (in) .528 – .813, .292 – .47, .998 – 1.152, .681 – .998, 1.217 – 1.39, .681 – 1.152, .332 – .681, .998 – 1.289, .813 – 1.152, .332 – .813, .813 – 1.289, .418 – .681, .373 – .681, 1.06 – 1.251, .292 – .681, 1.152 – 1.289, .528 – .998
-
Sheath Outside Diameter (mm) 52.07, 38.1, 66.04, 45.72
-
Sheath Outside Diameter (in) 1.5, 2.6, 1.8, 2.05
Body Features
-
Flexibility Semi-Flexible
-
Primary Product Color Black
-
Insulation Material Silicone Rubber
Industry Standards
-
Compatible With Approved Standards Products IEEE 404
Other
-
Product Use Power Cables
-
Installation Instruction English
-
EU RoHS Compliance Compliant, Compliant with Exemptions
-
EU ELV Compliance Compliant, Compliant with Exemptions
Product Availability
-
Product Availability Americas
Electrical Characteristics
-
Voltage Class (kV) ≤ 15, ≤ 35, ≤ 28
Configuration Features
-
Number of Cores 1
Reference Number
-
TE Internal Number CAT-CSJA-JCN
