Dimming Receptacle, Rotatable

Dimming Receptacle, Rotatable-CAT-ST833-R2435
  • LUMAWISE
|
  • LUMAWISE Endurance N
TE's ANSI C136.41 compliant LUMAWISE rotatable dimming receptacle is a two-piece assembly which allows rotation up to 355 degrees. The ability to fully rotate the dimming receptacle facilitates installation as it allows the photo node to be pointed due north in any type of street, area or roadway lighting application.
More Less

Available from

LADD Inc

Build and price the product now

Overview

TE Connectivity's ANSI C136.41 compliant LUMAWISE rotatable dimming receptacle provides an electrical and mechanical interconnection between an ANSI C136.41-2013 photo control cell and luminaire. Ideal for outdoor commercial and utility lighting the ANSI C136.41 compliant dimming receptacle is available with two or four dimming contacts to support either 0-10 VDC dimming methods or Digital Addressable Lighting Interface (DALI), while providing a reliable power interconnect with three robust twist lock contacts.

Applications

• Street and Roadway Lighting



• Photo controls



• Parking Lot Lighting

Benefits

• Rotates up to 355 degrees



• Robust twist lock contacts for a reliable power interconnect



• Receptacle comes pre-terminated with wire leads for ease of integration into new or existing light fixtures



• Available with 105° and 150° C rated wire insulation for varying temperature rated luminaires



• Accepts ANSI standard dimmable photocells to provide a connection between the photocell and the luminaire



• Available with two or four dimming contacts to support one or two channel dimming protocols


Explore Further

  1. 60 second Spotlight: Dimming Receptacle (English)

Product Manager Alex Hunt III explains why customers are so interested in our rotatable dimming receptacle and how it solves their installation challenges and helps speed the adoption of LEDs in street lighting applications driving energy efficiency and savings for end customers.

Dimming Receptacle video
Features

Please review product documents or contact us for the latest agency approval information.

Detailed product features are not currently available online.

Related Materials

Datasheets & Catalog Pages

Video

  • Dimming Receptacle (English) Product Manager Alex Hunt III explains why customers are so interested in our rotatable dimming receptacle and how it solves their installation challenges and helps speed the adoption of LEDs in street lighting applications driving energy efficiency and savings for end customers.
