Please review product documents or contact us for the latest agency approval information.

Please Note: Use the Product Drawing for all design activity.

• Factory Installed Backshell : No

• Number of Positions : 5

• Number of Power Positions : 0

• Number of Signal Positions : 5

• Contacts Preloaded : Yes

• Assembly Type : Electrical Connector

• Connector Product Type : Connector Assembly

• Circular Connector Shell Type : All Plastic

• Assembly Requirement : Factory Assembled

• Connector System : Cable-to-Cable

• Sealable : Yes

• Connector & Contact Terminates To : Wire & Cable

• Circular Connector Type : Plug

• Shell Type : Plastic

• Durability Rating (Cycles): 100

• Circuit Application : Signal

• Shielded : No

• Mating Alignment : With

• Mating Retention Type : Threaded Coupling

• Connector Mounting Type : Cable Mount (Free-Hanging)

• Polarization Code : A

• Mating Alignment Type : Keyed

• Peripheral Seal Material : Silicone

• Primary Product Color : Black

• Environmental Protection Type : Elastomer Sealed

• Environmental Protection : IP67

• O-Ring Material : Silicone

• Shell Plating Material : Unplated

• Shell Base Material : Plastic

• Circular Connector Insulation Material Type : Polyamide 66 GF25

• Hermetically Sealed : Yes

• IP Water Sealing Level : IP67

• IP Dust Sealing Level : 6

• Operating Temperature Range : -40 – 85 °C [ -40 – 185 °F ]

• Field Serviceable : Yes

• EU RoHS Compliance : Compliant with Exemptions

• EU ELV Compliance : Compliant with Exemptions

• Termination Method to Wire & Cable : Screw Terminal

• UL Flammability Rating : UL 94HB

• Packaging Quantity : 1

• Operating Voltage (VDC): 60

• Operating Voltage (VAC): 60

• Contact Current Rating (Max) (A): 4

• Reverse Gender : Yes

• Circular Connector Contact Type : Pin

• Circular Connector Shell Size : 20
