MetriMate Rectangular Plastic Connector Systems
TE Connectivity’s Rectangular Metrimate connectors are a rugged and cost-effective solution that can be used to provide power input and output to and from any device. Consisting of Square Grid and In-Line Connectors as well as Blind Mate Drawer Connectors the portfolio provides solutions for most needs. Rectangular Metrimate utilizes the same contact system and the same termination tooling as our highly successful Circular Plastic Connectors. This allows the customer to have a better-applied cost impact due to the overall shared platform with our CPC product line.
Product Features
| Connector Systems |
Wire-to-Wire, Wire-to-Board, Wire-to-Panel |
Connector Mounting Type |
Board Mount, Cable Mount, Panel Mount |
| Centerline (Pitch) (mm) |
4.39, 5, 5.08, 8 |
EU RoHS Compliance |
Compliant, Non Compliant |
| Number of positions |
3 to 36 |
EU ELV Compliance |
Compliant, Compliant with Exceptions |
| Connector & Contact Terminates To |
Printed Circuit Board, Wire & Cable |
Circuit Application |
Power, Power & Signal |
| Contact Current Rating (Max) (A) |
7.5, 13, 14, 47, 55 |
Featured Products
MetriMate
The Metrimate connector is a versatile and reliable electrical connector designed for a wide range of industrial applications. It provides secure and efficient connections between electrical devices, offering high-performance data and power transmission capabilities while ensuring durability and ease of use. Presently, connectors are available in various design configurations and the most popular sizes to satisfy a variety of application requirements. Such designs include: square grid connectors for free-hanging and/or panel mounting; free-hanging in-line connectors; square grid and in-line pin and socket headers for pc board mounting; and drawer connectors for rack and panel mounting with radial float.
Product Features
Download - AMP Metrimate Pin and Socket Connectors CatalogMetriMate Connectors
|
Max Current Rating
|
Max Voltage
|
Position Count
|
Wire Range (AWG/mm^2)
|
Power / Signal / Hybrid
|
Temperature Range (°C)
|
Blind Mating & Panel Mount
|
Configuration
|
Connector Type
|
Standards / Approval
|
50 |
600V |
1 - 36 |
30 - 8 AWG .05 - 8.0 mm^2 |
Power / Signal |
-55 to 120 |
Yes |
Wire-to-Wire, Wire-to-Board |
Rectangular, In-Line, Drawer |
UL, CSA |
MetriMate ConnectorsThis product table can only be viewed on desktop.
M-Series
The M-Series connectors are a robust and versatile solution for demanding industrial environments. These connectors offer high-reliability for power and data transmission, with features such as rugged construction, excellent sealing properties, and modular design options, making them ideal for applications where durability and performance are critical.
Product Features
Download - M Series Pin and Socket Connectors Data SheetM-Series
|
Max Current Rating
|
Max Voltage
|
Position Count
|
Wire Range (AWG/mm^2)
|
Power / Signal / Hybrid
|
Temperature Range (°C)
|
Panel Mount
|
Configuration
|
Connector Type
|
Standards / Approval
|
60 |
250V |
6 - 160CF |
30 - 8 AWG .05 - 8.0 mm^2 |
Power / Signal |
-55 to 150 |
Yes |
Wire-to-Wire, Wire-to-Board |
Rectangular |
UL, CSA |
M-SeriesThis product table can only be viewed on desktop.
Miniature Rectangular (MR) Series
The Miniature Rectangular (MR) Series is specifically designed for harsh and rugged environments. These connectors excel in providing reliable and secure connections for industrial applications where resistance to high temperatures, moisture and vibration is essential. With their durable construction and sealing capabilities, the MR connectors ensure optimal performance and protection in challenging conditions.
Miniature Rectangular - MR
|
Max Current Rating
|
Max Voltage
|
Position Count
|
Wire Range (AWG/mm^2)
|
Power / Signal / Hybrid
|
Temperature Range (°C)
|
Panel Mount
|
Configuration
|
Connector Type
|
Standards / Approval
|
9 |
250V |
2 - 36 |
26 - 18 AWG .12 - .80 mm^2 |
Power / Signal |
-55 to 85 |
Yes |
Wire-to-Wire, Wire-to-Board |
Rectangular |
UL, CSA |
MR-SeriesThis product table can only be viewed on desktop.
AMPINNERGY
AMPINNERGY Wire-to-Wire and Wire-to-Board Connectors provide a reliable and efficient means of interconnecting conductors employed to carry up to 600VAC in power circuits or networks. Furthermore, wire to wire connector housings, mounting adapters, and power terminals are all provided with keying features that make it difficult to improperly assemble and apply the connector. Wire-to-Board connectors are designed to be used in printed circuit boards and other power distribution devices in computers and peripherals along with appliances. Explore Product Specification and Application Specification for more details.
Product Features
Download - AMPINNERGY (Power Wiring Device) CatalogAMPINNERGY - Power Wiring Device
|
Max Current Rating
|
Max Voltage
|
Position Count
|
Wire Range (AWG/mm^2)
|
Power / Signal / Hybrid
|
Temperature Range (°C)
|
Panel Mount
|
Configuration
|
Connector Type
|
Standards / Approval
|
55 |
600V |
2 - 8 |
10 - 18 AWG |
Power |
0 to 105 |
No |
Wire-to-Wire, Wire-to-Board |
Rectangular |
UL, CSA |
AMPINNERGYThis product table can only be viewed on desktop.
